The difference between pressure sensors, transmitters, transducers and sensor modules

Michiel de Visser Marketing Manager
Date: September 11, 2024
Reading time: 3 Minutes

From the first day I started at Althen, I have been wondering what exactly is the difference between pressure sensors, transmitters, and transducers. With all the technical expertise around me, this always felt like a silly, and possibly even very stupid question to be asking. Because everybody seemed so extremely convinced to know the exact answer.

But let's start with a few personal confessions from my side. Of all the highly technical experts who normally write blog articles for you in this Sensor Experts Blog, as a marketeer I am kind of an "unusual suspect". So if you are expecting all kinds of highly technical treatises on sensor technology, I have to disappoint you in advance. Secondly, one of my personal development goals within Althen, is to work on my technical and product related knowledge.

Interchangeable terminology

Until an important internal discussion arose, I never, ever dared to ask the probably so obvious question, about the difference between pressure sensors, transmitters, and transducers. External sources were also unclear and  contradicting each other. Even websites from respectable manufacturers were not in line with each other. Eventually for me, it always felt like tomato tomato, the same thing. Until recent one of my esteemed colleagues, my technical guru, took the time, efforts, and probably gathered all his patience to calmly explain this to me once and for all.

Pressure sensors, the most basic type

Pressure sensors are used to detect and measure the pressure of gases or liquids and are widely used in automotive systems, medical devices , and industrial equipment. They convert physical pressure into an electrical signal. The core element of a pressure sensor is a sensing element, such as a diaphragm or piezoelectric crystal, which deforms under pressure. This deformation is then converted into a measurable electrical output, such as a change in resistance, capacitance, or voltage.

Best for basic detection and measurement

When your application for instance requires you to detect or measure pressure without needing to process or transmit the data over long distances, a basic pressure sensor is sufficient. In your possible applications where cost is a significant concern and the environment is not particularly harsh or demanding, basic pressure sensors are perfect for your task. These pressure sensors are relatively inexpensive and can be integrated into various devices with minimal additional circuitry.

Intrinsically safe pressure sensor

Pressure transducers

A pressure transducer is suitable when you need accurate measurements that need to be reliably converted into an electrical signal. Pressure transducers are more suitable for applications where pressure data needs to be converted directly into a voltage or current that is stable and accurate, but where extensive signal conditioning is not necessary. Transducers are commonly used in industrial processes, such as measuring pressure in hydraulic systems or gas lines.They are also popular in research and development environments, where accurate measurements are required in laboratory settings. A pressure transducer is the right choice when you need a signal that is immediately usable for further processing, without the need to apply additional amplification or filtering.

For localized measurement and specialized applications

When to use pressure transducers:

  • For localized measurement: If the application involves measuring pressure at a specific point and you need an analog output (e.g., 0-5V or 0-10V), pressure transducers are a good choice. They are often used in systems where the pressure data is needed locally or within short distances.
  • Specialized applications: Pressure transducers are versatile and can be used in a variety of specialized applications, such as laboratory testing, where precise and accurate measurements are required. Like in HVAC systems where pressure transducers monitor airflow and pressure in ducts to ensure the system is operating efficiently. Or in hydraulic systems or machinery where transducers measure the pressure within hydraulic lines, providing critical data to prevent overpressure conditions.

Pressure transmitters

Pressure transmitters are suitable for demanding industrial environments where the pressure signal needs to be transmitted over long distances, such as in large factories or plants. They provide a standardised, amplified signal (such as 4-20 mA) that is insensitive to electrical noise and interference. Like in the oil and gas industry pressure transmitters monitor and control pressure in pipelines, ensuring safe and efficient operations. And in for instance Water Treatment Plants they measure and transmit pressure data to control systems, which adjust pumps and valves to maintain optimal pressure levels.

Best for industrial applications and long-distance signal transmission

When to choose pressure transmitters:

  • In industrial environments: Pressure transmitters are designed for robust industrial applications where pressure data needs to be transmitted over long distances or integrated into complex control systems. For example, in oil refineries or chemical plants, transmitters convert the pressure signal into a 4-20mA current loop, which is less susceptible to signal loss or interference.
  • In process control situations: If you need to monitor and control pressure within a process (e.g., in a water treatment facility), pressure transmitters are essential. They provide accurate, reliable data that can be fed directly into control systems or SCADA (Supervisory Control and Data Acquisition) systems.
  • In harsh conditions: Pressure transmitters are often built to withstand harsh environmental conditions like for instance offshore, making them ideal for use in extreme temperatures, corrosive environments, or where high reliability is required.

And pressure sensor modules then?

Pressure sensor modules refer to pressure sensors integrated with additional components like an amplifier, filter, and sometimes even a micro-controller to provide a more complete solution for specific applications. The modules often feature enhanced performance characteristics, such as temperature compensation, linearization, and digital interfaces. They are typically used when the application requires more than just a basic sensor but does not need the full robustness of a pressure transmitter. A pressure sensor module is integrated with additional electronics for enhanced performance or specific application needs. They are often used in applications or systems where space and integration are key considerations. Choose a pressure sensor module when you want to quickly and easily integrate pressure measurements into an electronic system without worrying about analogue signal processing or calibration.

In conclusion

The choice between a pressure sensor, pressure transducer, pressure transmitter, or pressure sensor module strongly depends on your specific situation or project.

  • Choose pressure sensors when basic pressure detection or measurement is needed, and cost and simplicity are key concerns;
  • Choose pressure transmitters in industrial environments requiring robust, long-distance signal transmission, particularly in process control and harsh conditions;
  • Choose pressure transducers for localized measurement with specific output requirements, particularly in specialized or laboratory applications
  • Choose pressure sensor modules in compact, integrated applications, or when enhanced performance features are needed.

Personally I learned a lot form the feedback and literature I had to read by accomplishing one of my personal development goals with this first blog article. It helped me to understand the differences to a probably obvious question that everybody else seems to know the answer of.

Hopefully you saw that by understanding the specific requirements of your application, you can choose the right type of pressure measurement device, ensuring that it performs optimally and meets all necessary criteria. Making the right choice will ensure that your system works efficiently and meets the requirements of your specific application. Our team of technical experts will always be more than willing to help you with your project or challenge.
