750-100 Black Diamond Hoge Nauwkeurigheid Sensor
Precisie Vloeistof Gedempte Inclinometer
750-100 High Precision Tilt Meter
The 750-100 Tiltmeter is a rugged, high performance, single-axis tilt sensor designed for peak performance in extreme conditions. The fluid damped mechanism delivers superior noise rejection in high shock and vibration environments as well as excellent output stability.
Units are available with a 6-pin connector or pin-terminals. Available outputs include 0-5V and 4-20mA. Custom input ranges, filters and temperature compensation are also available on request.
Key features 750-100 Tilt Sensors
- Resolution of 1 µrad
- Temperature Compensation Available
- 0-5V Output
- +9 to +18 Volts DC Power Input
- RoHS Compliant
Applications 750-100
- High-precision Geotech
- Oil and Gas, Riser Tilt Monitoring
- Railroad MOW Equipment
- Pavement Profiling Rigs
- Vehicle Wheel Alignment
- Robotics
Black Diamond Series
The Black Diamond Series are low-cost, high-precision tilt sensors designed with higher accuracy than comparable MEMS devices. They are meant for geotechnical monitoring applications including bridge sag and sway, deflection measurement, platform leveling, and structural analysis.
Heeft u deze sensor nodig voor uw volgende project?
Vraag vandaag nog een offerte aan of laat uw gegevens achter voor meer informatie van een van onze experts.
Product downloaden
Doe het op uw manier
Niet precies wat u zoekt? Wij bieden standaard sensoren, maar kunnen u ook helpen met voor u aangepaste sensoren of een volledig op maat gemaakte meetoplossing. Neem contact met ons op voor advies of prijzen.
Praat met een expertTechnische specificaties
Specificaties | Waarde |
---|---|
Dimensions | 35 x 79 x 55 mm |
Output | 0-5VDC or 4-20mA |
Range | ±1°, ±3°, ±14.5°, ±30°, ±60°, ±90° |
Resolution | 1 µradian |
Seal | IP65 |
Temperature range | -40°C to +80°C |
