ASC 62C1 Piezoresistive Accelerometer
Uniaxial, small and compact acceleration sensor for testing light weight structures
About the ASC 62C1 Piezoresistive Accelerometer
The accelerometers are based on an advanced piezoresistive MEMS technology and can be used in a low frequency response up from 0Hz. The piezoresistive sensor element is made of monolithic resistors. These resistors are attached to carrier-elements and are electrically connected in a Wheatstone bridge. The electrical signal changes proportional to the vibration.
The model ASC 62C1 is an uniaxial accelerometer based on piezoresistive technology and factory calibrated. The ASC 62C1 is a very small and compact accelerometer which meets the specification SAE J211. Its housing is a cube form and hard anodised aluminium. Due to its low mass this model is ideal for testing light weight structures.
The sensing element has integrated overload stops and therefore the silicon chip is highly shock resistant. The ASC 62C1 has an excellent non-linearity over a wide frequency response. Electrically it is configured as a Wheatstone Bridge.
The ASC 62C1 can be obtained with all common sensor ID modules. A very high flexible and rugged cable provides a simple mounting. The ASC 62C1 is equipped as standard with 6 meter of this cable.
Key features ASC 62C1
- Uniaxial
- Wheatstone Bridge
- mV Output
- Aluminium Housing
- Made in Germany
- Range: 500g, 1000g and 2000g
- Very Small Size
- Light Weight
- DC Response
- ±5000g Shock Resistance
- Gas Damped
- 3-10Vdc Excitation
Options ASC 62C1
- Customised Cable Length
- Customised Connector
- TEDS Module
- Equipment Exchange (EQX)
Applications ASC 62C1
- Automotive Crash Testing
- Shock Testing
Do you need this sensor for your next project?
Request a no-obligation quote or send us your contact details for a free, no-obligation consultation. Our sales engineers will then contact you within a maximum of 1 to 2 working days.
Product downloads
Talk to our experts
Not exactly what you are looking for? We offer standard sensors, but can also help you with sensors adapted for you or a fully customised measurement solution. Contact us for advice or pricing.
Talk to an expertTechnical Specifications
| Specification | Value |
|---|---|
| Amplitude non-linearity (% fso) | ±1 |
| Excitation voltage (v dc) | 3 to 10 |
| Frequency response: ±5% | 2500 Hz |
| Operating temperature range (°c) | -20 to +80 |
| Range (±g) | 500 | 1000 |2000 |
| Resonance frequency (khz) | 15 | 15 | 26 |
| Sensitivity (mv/g) | 0.4 | 0.15 | 0.13 |
| Shock limit (±g) | 5000 |
| Weight (gram, without cable) | 3 |
