LCF-2530 Servo Accelerometers

2-axis servo acceleration sensor ideal for rail maintenance of way applications


About the LCF-2530 Servo Accelerometers

The LCF-2530 Series is a dual axis version of the rugged, high accuracy LCF Series. The design of the LCF-2530 was optimized to provide the high suspension, servo technology in a small and convenient package for applications requiring a compact dual axis solution.

Key features LCF-2530

  • Filtering 5-100 Hz Bandwidt Available
  • Exeptional Bias & Scale Factor Repeatability
  • Built In Temperature Sensor Available
  • Fluid Damped
  • High Accuracy Dual Axis in Small Package
  • Superior Bias Stability
  • Low EMI



Applications LCF-2530

  • Railcar Accel/Decel Control
  • Train Performance Testing
  • Active Damping
  • Rail Car Harshness (NVH)
  • Manual Rail Measurement

Do you need this sensor for your next project?

Request a no-obligation quote or send us your contact details for a free, no-obligation consultation. Our sales engineers will then contact you within a maximum of 1 to 2 working days.

Talk to an expert

Talk to our experts

Not exactly what you are looking for? We offer standard sensors, but can also help you with sensors adapted for you or a fully customised measurement solution. Contact us for advice or pricing.

Talk to an expert

Technical Specifications

Specification Value
Bandwidth (-3 db) (nom) 30.0 Hz
Input current (max) 50 mA
Measurement range ±0.25 g / ±0.5 g / ±1.0 g / ±2.0 g / ±5.0 g
Non-linearity 0.10 - 0.05%
Operating temperature -40°C to +80°C
Output [supply voltage] ±5.0 VDC [±12 to ±18 VDC]
Resolution and threshold (max) 1 μg
Seal MIL-STD-202, Method 112, IP65
Shock 1000 g, 1 msec, ½ sine
Storage temperature -60°C to +90°C
Vibration 20 g
Weight 8 oz
