MP-1.55 Ultra Miniature Flat Pressure Sensor
For standard and high temperature, highest 2.7 MHz resonance frequency available in the market
Key features
- L x W: 1.55mm x 3mm
- From 2 to 7 bar / absolute pressure
- Burst pressure 7 bar
- Wide temperature range up to 100°C or 185°C (depending on model)
- Suitable for harsh environments
- mVolt output
About the MP-1.55 Ultra Miniature Flat Pressure Sensor
This pressure sensor is the smallest of its kind - without any performance restrictions! It offers the highest resonant frequency of 2.7 MHz available on the market. There are two different models, one for temperatures up to 100°C (ST) and one for high temperatures up to 185°C (HT).
Special cable lengths, materials and grid shapes are available on request.
Key features
- L x W: 1.55mm x 3mm
- From 2 to 7 bar / absolute pressure
- Burst pressure 7 bar
- Wide temperature range up to 100°C or 185°C (depending on model)
- Suitable for harsh environments
- Customised solution possible
- mVolt output
Highest resonant frequency on the market - Amplification can be performed on request
Applications
- Instrumentation (e.g. automotive industry, ...)
- Aerodynamic tests (e.g. wind tunnel)
- Industrial process monitoring
- Pumps
- Biomedical applications
- Oil and gas
Do you need this sensor for your next project?
Request a no-obligation quote or send us your contact details for a free, no-obligation consultation. Our sales engineers will then contact you within a maximum of 1 to 2 working days.
Product downloads
Talk to our experts
Not exactly what you are looking for? We offer standard sensors, but can also help you with sensors adapted for you or a fully customised measurement solution. Contact us for advice or pricing.
Talk to an expertTechnical Specifications
| Specification | Value |
|---|---|
| Accuracy | 0.25% @FS |
| Excitation voltage | 5 V |
| Max. temperature | 100 °C (ST) | 185 °C (HT) |
| Pressure range | 0 - 100 PSI / 0 - 7 bar |
| Proof pressure | 3 * nominal |
